Description:
The reComputer J4012 is a powerful and compact edge AI device with NVIDIA® Jetson Orin™ NX SoM, pre-built Jetpack 5.1.1, 128GB SSD, 4x USB 3.2, HDMI, GbE, carrier board also includes M.2 Key E for WIFI, M.2 Key M for SSD, RTC, CAN, 40-pin, and more.
Features:
AI Performance: Achieves 100 TOPS, making it suitable for demanding AI applications.
Power Efficiency: Operates within a power consumption range of 10W to 25W.
Wide Range Operation Temperature: Designed to function reliably in temperatures from -10°C to 60°C.
Open Source Hardware: Commitment to flexibility and community-driven development.
Specifications:
Jetson Orin NX System on Module
AI Performance: 100 TOPS
GPU: 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores
CPU: 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU (Orin NX 16GB)
Memory: 16GB 128-bit LPDDR5 (Orin NX 16GB)
Video Encode: 1x 4K60 (H.265) | 3x 4K30 (H.265) | 6x 1080p60 (H.265) | 12x 1080p30 (H.265)
Video Decode: 1x 8K30 (H.265) | 2x 4K60 (H.265) | 4x 4K30 (H.265) | 9x 1080p60 (H.265) | 18x 1080p30 (H.265)
DL Accelerator: 2x NVDLA v2
Carrier Board
Storage: 1x M.2 Key M PCIe (M.2 NVMe 2280 SSD 128G included)
Ethernet: 1x RJ-45 Gigabit Ethernet (10/100/1000M)
M.2 KEY E: 1x M.2 Key E for WiFi/Bluetooth module（module not included）
USB: 4x USB 3.2 Type-A (10Gbps); 1x USB2.0 Type-C (Device Mode)
Camera: 2x CSI (2-lane 15pin)
Display: 1x HDMI 2.1
Fan: 1x 4 pin Fan Connector (5V PWM)
CAN: 1x CAN
Multifunctional Port: 1x 40-Pin Expansion header; 1x 12-Pin Control and UART header
RTC: 1x RTC 2-pin, supports CR1220 (not included)
Power: 9-19V DC
Dimensions (W x D x H): 130mm x 120mm x 58.5mm (with case)
Installation: Desk, wall-mounting
Operating Temperature: -10℃~60℃
Hardware Overview:
reComputer J401 carrier board, included in the full system - reComputer J4012
Desktop, wall Mount, expandable, or fit anywhere
Application:
- AI Video Analytics
- Machine Vision
- Autonomous Mobile Robot (AMR)
- Generative AI
Documents:
Part List:
1x reComputer J4012 (System Installed)
1x 12V/5A(Barrel Jack 5.5/2.5mm) Power Adapter (Power cord not included)
Note: Please note that the product comes with a power adapter, but does not include an AC cloverleaf power cord. Kindly purchase the appropriate AC cloverleaf power cord based on your local power socket specifications.
